Long Pulse 40ms and 100ms
UMT
40ms and 100ms
Flexible, High-Performance Solution for Solar Panel Testing
The High LIGHT Long Pulse sets a new benchmark in solar panel testing, combining state-of-the-art optics with cutting-edge measurement technology. Our HighLIGHT deliver unmatched accuracy and consistency, ensuring superior optical performance with uniformity and intensity across the solar spectrum for precise and reliable measurements.
Key Features & Advantages
→ Unparalleled Optical Performance
→ Class A+A+A+ compliance (IEC 60904-9 ed.3)
→ Non-uniformity: < 1%
→ Spectral Match: ± 12.5% (300-1200nm AM1.5)
→ Spectral Uniformity: A+
→ Long-Term Instability (LTI): < 0.5%
→ Exceptional Illumination
→ Pulse duration: Up to 100 ms
→ Cycle time: < 15 seconds
→ Illuminated area: 2,800 x 1,600 mm
→ Innovative Measurement Capabilities
→ Repeatability: < 0.05% on Isc, Voc, and Pmax
→ Advanced methods: Linear Sweep, DragonBack,
SmartSweep, MultiFlash, Partial Measurement, and more
Why Choose the HighLIGHT UMT?
→ Flexibility and Versatility: Long pulse durations and innovative
measurement techniques allow for the efficient
characterization of high-capacitance solar panels.
→ Superior Accuracy: A+ uniformity in both irradiance and
spectrum ensures highly accurate PV measurements.
→ Future-Proof Design: Scalable with add-ons and accessories
to adapt to evolving testing requirements.
The HighLIGHT UMT is your ultimate solution for high-precision, reliable, and scalable solar panel testing.
