HighLIGHT SMT+

HighLIGHT UMT 40ms and 100ms


Flexible, High-Performance Solution for Solar Panel Testing



The HighLIGHT UMT sets a new benchmark in solar panel testing, combining state-of-the-art optics with cutting-edge measurement technology. Our HighLIGHT deliver unmatched accuracy and consistency, ensuring superior optical performance with uniformity and intensity across the solar spectrum for precise and reliable measurements.

Key Features & Advantages

  • Unparalleled Optical Performance
    • Class A+A+A+ compliance (IEC 60904-9 ed.3)
    • Non-uniformity: < 1%
    • Spectral Match: ± 12.5% (300-1200nm AM1.5)
    • Spectral Uniformity: A+
    • Long-Term Instability (LTI): < 0.5%
  • Exceptional Illumination
    • Pulse duration: Up to 100 ms
    • Cycle time: < 15 seconds
    • Illuminated area: 2,800 x 1,600 mm
  • Innovative Measurement Capabilities
    • Repeatability: < 0.05% on Isc, Voc, and Pmax
    • Advanced methods: Linear Sweep, DragonBack, SmartSweep, MultiFlash, Partial Measurement, and more

Why Choose the HighLIGHT UMT?

  • Flexibility and Versatility: Long pulse durations and innovative measurement techniques allow for the efficient characterization of high-capacitance solar panels.
  • Superior Accuracy: A+ uniformity in both irradiance and spectrum ensures highly accurate PV measurements.
  • Future-Proof Design: Scalable with add-ons and accessories to adapt to evolving testing requirements.

The HighLIGHT UMT is your ultimate solution for high-precision, reliable, and scalable solar panel testing.
