SpotLIGHT
Cell Tester
Built for the cell line. SpotLIGHT was the first xenon tester able to measure high-capacitance cells without the transient error that corrupts a standard flash, compact enough for the lab, fast enough for production, and ready for PERC, HJT, TOPCon, bifacial and curved cells.
single cell · sub-second · capacitive-readyThe transient that breaks a fast flash.
High-efficiency cells store charge; flash them too quickly and the IV curve lies. SpotLIGHT's xenon pulse and measurement electronics give the cell time to settle, so PERC, HJT and bifacial devices are characterised accurately, at production speed.
- ▸Cell typesPERC · HJT · TOPCon · bifacial
- ▸Speedsub-second per cell
- ▸Curvefull I–V, non-shunted
- ▸Footprint64 × 72 × 140 cm
Contact without damage.
Modern busbarless cells can't be soldered for a quick test. With the GridTOUCH temporary contacting system, SpotLIGHT measures next-generation architectures with zero damage and full-curve accuracy, lab characterisation and inline sorting from one platform.
- ▸ContactingGridTOUCH (temporary)
- ▸Damagenone, no solder marks
- ▸Uselab + inline sorting
- ▸Architecturesbusbarless · HJT
